LED Anbauleuchte, Lichtverteilung symmetrisch, direkt/indirekt, Gehäuse aus stranggepresstem Aluminium pulverbeschichtet, Passive Kühlung aus Aluminium, mit opaler Abdeckung, Treiber nicht dimmbar im Gehäuse integriert, Farbe weiß RAL 9016
DAL 651 Opal direkt/indirekt
Beschreibung
Optional:
Lichtverteilung nur direkt, Treiber Dali dimmbar, Farbe weißaluminium RAL 9006 oder schwarz RAL 9005
Durchmesser 410mm
| 11,4 W | 1580lm | 3000k | CRI>80 | D | L80/B20 50.000h | 35.04103080115.1031 |
| 10 W | 1450lm | 4000k | CRI>80 | D | L80/B20 50.000h | 35.04104080105.1031 |
| 22,1 W | 3040lm | 3000k | CRI>80 | D | L80/B20 50.000h | 35.04103080225.1031 |
| 20,8 W | 3000lm | 4000k | CRI>80 | D | L80/B20 50.000h | 35.04104080205.1031 |
| 36,5 W | 4990lm | 3000k | CRI>80 | D | L80/B20 50.000h | 35.04103080365.1031 |
| 35,2 W | 5040lm | 4000k | CRI>80 | D | L80/B20 50.000h | 35.04104080355.1031 |
Durchmesser 501mm
| 15,2 W | 2030lm | 3000k | CRI>80 | D | L80/B20 50.000h | 35.05013080155.1031 |
| 16 W | 2040lm | 4000k | CRI>80 | D | L80/B20 50.000h | 35.05014080165.1031 |
| 28,1 W | 3570lm | 3000k | CRI>80 | D | L80/B20 50.000h | 35.05013080285.1031 |
| 26,5 W | 3530lm | 4000k | CRI>80 | D | L80/B20 50.000h | 35.05014080265.1031 |
| 42,1 W | 5550lm | 3000k | CRI>80 | D | L80/B20 50.000h | 35.05013080425.1031 |
| 43,6 W | 5500lm | 4000k | CRI>80 | D | L80/B20 50.000h | 35.05014080435.1031 |
Durchmesser 630mm
| 18,2 W | 2620lm | 3000k | CRI>80 | D | L80/B20 50.000h | 35.06303080185.1031 |
| 17 W | 2550lm | 4000k | CRI>80 | D | L80/B20 50.000h | 35.06304080175.1031 |
| 25,2 W | 3630lm | 3000k | CRI>80 | D | L80/B20 50.000h | 35.06304080255.1031 |
| 24 W | 3600lm | 4000k | CRI>80 | D | L80/B20 50.000h | 35.06304080245.1031 |
| 36,4 W | 5130lm | 3000k | CRI>80 | D | L80/B20 50.000h | 35.06304080365.1031 |
| 33,9 W | 4990lm | 4000k | CRI>80 | D | L80/B20 50.000h | 35.06304080335.1031 |
| 54,2 W | 7450lm | 3000k | CRI>80 | D | L80/B20 50.000h | 35.06304080545.1031 |
| 51,6 W | 7420lm | 4000k | CRI>80 | D | L80/B20 50.000h | 35.06304080515.1031 |
Durchmesser 804mm
| 29 W | 4060lm | 3000k | CRI>80 | D | L80/B20 50.000h | 35.08043080295.1031 |
| 27,8 W | 4070lm | 4000k | CRI>80 | D | L80/B20 50.000h | 35.08044080275.1031 |
| 39 W | 5500lm | 3000k | CRI>80 | D | L80/B20 50.000h | 35.08043080395.1031 |
| 37,3 W | 5500lm | 4000k | CRI>80 | D | L80/B20 50.000h | 35.08044080375.1031 |
| 58 W | 8070lm | 3000k | CRI>80 | D | L80/B20 50.000h | 35.08043080585.1031 |
| 55,2 W | 8030lm | 4000k | CRI>80 | D | L80/B20 50.000h | 35.08044080555.1031 |
| 80,5 W | 11000lm | 3000k | CRI>80 | D | L80/B20 50.000h | 35.08043080805.1031 |
| 77,6 W | 11070lm | 4000k | CRI>80 | D | L80/B20 50.000h | 35.08044080775.1031 |
Technische Daten
| Durchmesser | 410/501/630/804mm |
| Höhe | 24/46mm |
